Suitable for small workboats and fishing vessels that do not require type approval, custom options or complex packaging
Available as a fixed specification featuring HX cooling with IMO emissions certification from China Classification Society (CCS)
Covered by a comprehensive one year warranty
All parts are available to order from the CCEC Regional Parts Distribution Centers
Built in Chongqing, China

Performance Curve of CCEC KTA19-DM448 Diesel Engine

A complete engine with all necessary accessories mainly includes followings:

Working together with our business partner Hispeed and Hangzhou Advance, we are able to provide a complete engine power pack for all shipyard customers all over the world. We can provide the complete service from design, supply, installation to commissioning ; for more information, please visit www.hispeed-boat.com, www.advance-gearbox.com.

User Guidelines

1. The operating should not be out range of the approved number of people and cargo weight.

2. You should take new engine checking and mileage compulsory maintenance when beyond the running travelled distance.

3. You should be clearly that you can’t modify the structure of the engine.

4. if you need to change the spare parts, make sure that you use original spare parts. After-market parts might damage your engine.

5. The quality of lubricating oil using on mechanical B series engine should not lower than API CF-4/SG standard, the viscosity is 15W-40 or when using in the arctic climate 10W-30 and 5W-20. The quality of lubricating oil using on electronic B & C series engine should not than API CH-4/SJ Performance range, the viscosity is 15W-40 or when using in the arctic climate 10W-30 and 5W-20.

6. Your engine must use antifreeze anti-rusted solution, and should change the liquid timely. CCEC recommend to use composite coolant or 50/50 high quality water mix with composite anti freeze.

a. The high quality water should meet all technical requests: concentration of chloride is lower than 40ppm, concentration of sulfate is lower than 100ppm, calcium/magnesium is lower than 170ppm; the prior choice is ionized water, distilled water or softened water.

b. Glycol working range between 40-60% is acceptable.

c. The concentration of SCA is in the range of 0.3-0.8.
