MTAA11-G3
|
 CCEC MTAA11-G3 Engine for Generator Set Application |
||||||||||||||||||||||||||||
CCEC MTAA11-G3 G-Drive Diesel Engine
| General Information of CCEC MTAA11-G3 G-Drive Diesel Engine | |
| Engine Model | MTAA11-G3 |
| Engine Type | 6 Cylinders in Line |
| Displacement | 11 L |
| Bore*Stroke(mm) | 125 * 147 |
| CPL Number | CQ223 |
| Net Weight (with flywleel & alternator) | 973 Kg |
| Overall Diemension(L*W*H) | 1306*914*1280 |
| Technical Specification of CCEC MTAA11-G3 G-Drive Diesel Engine | |
| Fuel System | Direct Injection |
| Aspiration | Turbocharged & Air-air Intercooled |
| Governing Rate | ?5% |
| Electrical System(Starter Motor/Alternator) | 12V/24V |
| Lowest Starting speed without auxiliary system -r/min | 150 |
| Engine Cooling Fluid Volume | 9.5 L |
| Performance Data of CCEC MTAA11-G3 G-Drive Diesel Engine | |
| Rated Power/Speed | 282 kW/384HP @ 1500rpm |
| Standby Power/Speed | 240 kW/322HP @ 1500rpm |
| Peak Torque | 1356 N.m |
| Fuel Consumption @ Rated Power | 188g/Kw.h |
| Fuel Consumption @ Standby Power | 192g/Kw.h |
| Idel Speed | 850 – 950 rpm |
This date sheet is for CCEC 50Hz G-Drive Engine. (60Hz G-Drive also available on request). Welcome to contact us for more information of CCEC MTAA11-G3 G-Drive Diesel Engine.
Click here to find engine spare parts for CCEC MTAA11-G3 G-Drive Diesel Engine
